As a high‑performance Chainway RFID reader and mobile terminal, it acts as the great hardware backbone in Million Tech’s RFID solutions, which have already delivered remarkable success stories in Smart Education and Smart Healthcare projects.
| Dimensions | 161.0 x 77.8 x 15.5mm / 6.34 x 3.06 x 0.61in |
|---|---|
| Weight | 297g / 10.48oz. (device with battery) |
| Display | 6-inch high definition display (18:9), 1440 x 720 |
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Power | 5000mAh removable main battery, support QC3.0 and RTC; Support Battery Management System; Hot swap battery backup |
| Notification | Sound, LED indicator, vibrator |
| Interfaces | USB Type-C, USB 3.1, OTG |
| Card slot | 1 for SIM card, 1 for SIM or TF card, Supports eSIM (optional) |
| Audio | 2 microphones, 1 for noise cancellation; 1 speaker; 1 receiver |
| Keypad | Power key, 2 scan keys, volume (+/-) keys, 1 multifunctional key |
| Sensors | G_sensor, proximity sensor, light sensor, geomagnetic sensor, gyroscope |
| WLAN | Support 802.11 a/b/g/n/ac/ax-6E, 2.4G/5G tri-band, IPV4, IPV6; 2*2 MIMO antennas |
| WWAN | 2G: GSM / EDGE / GPRS (850/900/1800) |
| Bluetooth | Bluetooth 5.2 |
| Vo-LTE | Support Vo-LTE HD video voice call |
| GNSS | GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna |
| Operating System | Android 14 |
| SDK | Chainway Software Development Kit |
| Language | Java |
| Tool | Eclipse / Android Studio |
| CPU | Qualcomm Octa-core, 2.4GHz |
| RAM+ROM | UFS: 4GB + 64GB / 8GB + 256GB (optional) |
| Expansion | Supports up to 256GB TF card |
| Operating Temp. | -4°F to 122°F / -20°C to +50°C |
| Storage Temp. | -40°F to 158°F / -40°C to +70°C |
| Humidity | 5%RH – 95%RH non condensing |
| Drop Specification | Multiple 1.5m / 4.92ft. drops to the concrete across the operating temperature range |
| Tumble Specification | 1000 x 0.5m / 1.64ft. falls at room temperature |
| Sealing | IP67 per IEC sealing specifications |
| ESD | ±15 KV air discharge, ±8 KV conductive discharge Communication |
| 2D Scanner | Zebra: SE4710; SE55; CM60 |
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. |
| 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc. |
| Front Camera | 5MP |
| Rear Camera | 16MP Autofocus with flash |
| NFC Frequency | 13.56MHz |
| Protocol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. |
| Chips | M1 card (S50, S70), CPU card, NFC tags, etc. |
| Range | 2-4cm |
